How to guide for filtering Sigma 8-16 on the cheap

PostTue Mar 19, 2013 4:55 am

Use 77mm or 82mm filters on your Sigma 8-16

Sorry I don't have any photos yet, but this process is pretty straight forward.

1) Purchase some Schedule 40 4" PVC pipe
2) Cut about 1/2" off of the end
3) Attach an 86->82mm STEP DOWN ring to the end of the PVC pipe using some gorilla tape around the edges.

4) At this point, the PVC pipe is too wide of a diameter to fit properly over the sigma lens. Two options:

a) Buy a new sigma lens cap, cut it, and attach the pipe to it. I have the lens cap but haven't gone this route yet.

b) Add some padding to the inside of the PVC so that it fits snugly over the sigma lens. I used two layers of 3M Heavy Duty mounting tape, leaving the red plastic backing on. It is a perfect fit.

5)
If you have an 82mm filter, you can attach this to the bracket and then mount it on your lens. Although I haven't tried, I suspect that you can do a full 8mm with an 82mm filter.

Otherwise purchase a 82mm->77mm STEP DOWN ring. Then use 77mm filters.

You will get some vignetting with 77mm filters at 8mm. If you are shooting 2.4:1 then it is not a problem. Otherwise you need to zoom to approximately 9.5mm to completely clear up the vignetting.

Hope this helps people filter their 8-16 lenses!

Scott
Offline

Scott Pultz

  • Posts: 550
  • Joined: Wed Jan 16, 2013 12:36 am
  • Location: Seattle

Re: How to guide for filtering Sigma 8-16 on the cheap

PostTue Mar 19, 2013 4:56 am

P.S. I would love to post this on BMCUser, but I have not been able to verify my email and I can't make a post asking for him due to this issue. So if somebody can help me out there then I can spread the word to them on this topic as well!
Offline
User avatar

Thomas Schumacher

  • Posts: 665
  • Joined: Tue Nov 06, 2012 11:14 pm
  • Location: Germany

Re: How to guide for filtering Sigma 8-16 on the cheap

PostTue Mar 19, 2013 9:55 am

Scott,

thanks a ton, great! One plea: could you provide some pictures for the ones like me (not native English speaker so some terms might be more obvious with a pic beside and mechanically dumb).

I can copy and paste your instrcutions and post it at BMCuser if you want me to.

EDIT: http://www.bmcuser.com/showthread.php?3 ... #post54101
My award-winning doc: https://vimeo.com/91622063
ARE YOU HAPPY? https://vimeo.com/72724154
http://www.gernemehrfilm.de/
https://berlin3500.wordpress.com/
Offline

Scott Pultz

  • Posts: 550
  • Joined: Wed Jan 16, 2013 12:36 am
  • Location: Seattle

Re: How to guide for filtering Sigma 8-16 on the cheap

PostWed Mar 27, 2013 11:41 pm

Sorry I still haven't had time to post pictures.

However I can confirm that using this technique and an 82mm filter, there are no vignetting problems at 8mm on the Sigma or with the Samyang 8mm Fisheye! This is great news for the fisheye. In my opinion 77mm filters on the 8-16 at 9.5mm is also fine.
Offline
User avatar

Hearnia

  • Posts: 109
  • Joined: Tue Nov 27, 2012 3:05 pm
  • Location: Delray Beach FL

Re: How to guide for filtering Sigma 8-16 on the cheap

PostThu Mar 28, 2013 10:50 am

Thanks a lot. Going to try this.
vimeo.com/hearnstudios
Offline
User avatar

Thomas Schumacher

  • Posts: 665
  • Joined: Tue Nov 06, 2012 11:14 pm
  • Location: Germany

Re: How to guide for filtering Sigma 8-16 on the cheap

PostThu Mar 28, 2013 5:15 pm

Hearnie,

it would be awesome if you can post a photo then! THX!
My award-winning doc: https://vimeo.com/91622063
ARE YOU HAPPY? https://vimeo.com/72724154
http://www.gernemehrfilm.de/
https://berlin3500.wordpress.com/
Offline
User avatar

Hearnia

  • Posts: 109
  • Joined: Tue Nov 27, 2012 3:05 pm
  • Location: Delray Beach FL

Re: How to guide for filtering Sigma 8-16 on the cheap

PostFri Mar 29, 2013 3:22 pm

I had to order the step down rings. I will post photos when I do it.
vimeo.com/hearnstudios
Offline
User avatar

Thomas Schumacher

  • Posts: 665
  • Joined: Tue Nov 06, 2012 11:14 pm
  • Location: Germany

Re: How to guide for filtering Sigma 8-16 on the cheap

PostFri Mar 29, 2013 3:40 pm

Thanks, looking forward to it!
My award-winning doc: https://vimeo.com/91622063
ARE YOU HAPPY? https://vimeo.com/72724154
http://www.gernemehrfilm.de/
https://berlin3500.wordpress.com/
Offline
User avatar

Hearnia

  • Posts: 109
  • Joined: Tue Nov 27, 2012 3:05 pm
  • Location: Delray Beach FL

Re: How to guide for filtering Sigma 8-16 on the cheap

PostTue Apr 02, 2013 12:14 am

Scott can you describe how to attach the 86mm step down ring to the PVC pipe? Mine looks quite a bit smaller than the pvc pipe - like tape just wouldn't attach it in the first place.
vimeo.com/hearnstudios
Offline
User avatar

Hearnia

  • Posts: 109
  • Joined: Tue Nov 27, 2012 3:05 pm
  • Location: Delray Beach FL

Re: How to guide for filtering Sigma 8-16 on the cheap

PostSun Apr 07, 2013 8:46 pm

Here's how I did this. I found a rubber plumbing pipe with a screw clamp instead of PVC. I found it in Home Depot in the same aisle as the PVC. I like this solution much better. It does work also; my 77mm ND filter works from about 9.5mm onwards, just like he said. There's a small amount of vignetting at 8mm. If you were cropping anamorphic you could probably get away with it.



vimeo.com/hearnstudios
Offline
User avatar

Thomas Schumacher

  • Posts: 665
  • Joined: Tue Nov 06, 2012 11:14 pm
  • Location: Germany

Re: How to guide for filtering Sigma 8-16 on the cheap

PostSun Apr 07, 2013 9:03 pm

Thanks a lot Hearnia!
My award-winning doc: https://vimeo.com/91622063
ARE YOU HAPPY? https://vimeo.com/72724154
http://www.gernemehrfilm.de/
https://berlin3500.wordpress.com/
Offline
User avatar

Thomas Schumacher

  • Posts: 665
  • Joined: Tue Nov 06, 2012 11:14 pm
  • Location: Germany

Re: How to guide for filtering Sigma 8-16 on the cheap

PostWed Apr 17, 2013 4:43 am

E D I T for intelligibility:

Just got my BMC and a owldolly matte box II, which let me put a filter in front without vignetting at 8mm:
Attachments
Last edited by Thomas Schumacher on Mon Jun 03, 2013 9:38 am, edited 2 times in total.
My award-winning doc: https://vimeo.com/91622063
ARE YOU HAPPY? https://vimeo.com/72724154
http://www.gernemehrfilm.de/
https://berlin3500.wordpress.com/
Offline

Darryl Gregory

  • Posts: 939
  • Joined: Sun Dec 16, 2012 2:49 am
  • Location: LA

Re: How to guide for filtering Sigma 8-16 on the cheap

PostWed Apr 17, 2013 6:19 am

I would rather pay someone to make this, I don't have the time or patients...Any takers?
Offline
User avatar

Hearnia

  • Posts: 109
  • Joined: Tue Nov 27, 2012 3:05 pm
  • Location: Delray Beach FL

Re: How to guide for filtering Sigma 8-16 on the cheap

PostWed Apr 17, 2013 11:14 am

Darryl Gregory wrote:I would rather pay someone to make this, I don't have the time or patients...Any takers?

I'll trade you one. Buy me an SLR Magic 25 for the pocket camera.
vimeo.com/hearnstudios
Offline
User avatar

Adrian Musto

  • Posts: 36
  • Joined: Wed Nov 28, 2012 1:03 pm
  • Location: London, UK

Re: How to guide for filtering Sigma 8-16 on the cheap

PostWed Apr 17, 2013 3:29 pm

Darryl Gregory wrote:I would rather pay someone to make this, I don't have the time or patients...Any takers?


Just buy a Tokina 11-16mm. I'm selling my Sigma on eBay to get a Tokina now that the flange issue has been solved, its not fast enough and the filter issue is a pain in the backside. I have a lovely 77mm Heliopan Variable ND that I can't use on the Sigma.
Offline

Carlos Delilah

  • Posts: 28
  • Joined: Wed Aug 22, 2012 7:01 am

Re: How to guide for filtering Sigma 8-16 on the cheap

PostTue Apr 23, 2013 8:23 pm

So at what fstop does this lens start to look like crap? what is the sweet spot or ideal aperture?
Offline

Scott Pultz

  • Posts: 550
  • Joined: Wed Jan 16, 2013 12:36 am
  • Location: Seattle

Re: How to guide for filtering Sigma 8-16 on the cheap

PostTue Apr 23, 2013 10:27 pm

Adrian Musto wrote:
Darryl Gregory wrote:I would rather pay someone to make this, I don't have the time or patients...Any takers?


Just buy a Tokina 11-16mm. I'm selling my Sigma on eBay to get a Tokina now that the flange issue has been solved, its not fast enough and the filter issue is a pain in the backside. I have a lovely 77mm Heliopan Variable ND that I can't use on the Sigma.


Unless your filter blocks IR, you probably won't want to use it for higher ND values.
Offline

Scott Pultz

  • Posts: 550
  • Joined: Wed Jan 16, 2013 12:36 am
  • Location: Seattle

Re: How to guide for filtering Sigma 8-16 on the cheap

PostTue Apr 23, 2013 10:29 pm

cls105 wrote:So at what fstop does this lens start to look like crap? what is the sweet spot or ideal aperture?


Tough call. At F16 the diffraction blurs out the moire/aliasing that this camera exhibits. The downside is that any significant dust on the front of your lens will be visible.

Around F8 is good if you aren't in a heavy aliasing situation...
Offline

Scott Pultz

  • Posts: 550
  • Joined: Wed Jan 16, 2013 12:36 am
  • Location: Seattle

Re: How to guide for filtering Sigma 8-16 on the cheap

PostSat Apr 27, 2013 5:52 pm

I no longer have a BMCC and am looking to sell my Sigma 8-16mm with filter adapters.

Email me at:
scott pultz ( @ ) hotmail . com

Remove the spaces and the ( ) and you have my address
