BMPCC 6K keeps stopping

The place for questions about shooting with Blackmagic Cameras.
  • Author
  • Message
Offline

Yellowfin

  • Posts: 9
  • Joined: Sat Sep 07, 2019 7:26 am
  • Real Name: Justin Hewitt

BMPCC 6K keeps stopping

PostWed Sep 11, 2019 10:54 am

Folks.

My new BMPCC 6K, will only record for a second or two and then stops.
in 6K recording mode it will record for 1(sec).28 and then stop with exclamation mark in the RED dot

I have turned OFF the "stop on dropped frames" option

The recording media is SDXC R300MB/s W299MB/s card.

** In ProRES is will record up to 1 minute.

What is causing this, I the unit faulty ?

Justin.
Offline
User avatar

carlomacchiavello

  • Posts: 700
  • Joined: Tue Aug 28, 2012 6:04 pm
  • Location: italy

BMPCC 6K keeps stopping

PostWed Sep 11, 2019 4:26 pm

Your media is in approved list?
If you put name I could check for you.
Check the supported media in support site of Blackmagic Design.
I not think can sustain enough to write speed for a 6k. Try braw 12:1, and later try to up and check but I not think is certified by Blackmagic Design for that kind of video


Inviato dal mio iPhone utilizzando Tapatalk
Offline

Dune00z

  • Posts: 225
  • Joined: Thu Oct 18, 2018 3:40 pm
  • Real Name: Duane Eues

Re: BMPCC 6K keeps stopping

PostWed Sep 11, 2019 9:54 pm

There is not nearly enough information provided to get help on this. You haven't indicated what compression you are using, what codec, brand name or model of media, etc.

You need to be specific in your details to get help.

The most likely situation is that the storage media does not have a high enough consistent write speed for the media and it likely isn't a faulty storage unit, but this is shooting in the dark.
Offline

Que Thompson

  • Posts: 303
  • Joined: Thu Jan 24, 2013 10:19 pm

Re: BMPCC 6K keeps stopping

PostWed Sep 11, 2019 9:55 pm

Yellowfin wrote:Folks.

My new BMPCC 6K, will only record for a second or two and then stops.
in 6K recording mode it will record for 1(sec).28 and then stop with exclamation mark in the RED dot

I have turned OFF the "stop on dropped frames" option

The recording media is SDXC R300MB/s W299MB/s card.

** In ProRES is will record up to 1 minute.

What is causing this, I the unit faulty ?

Justin.


:lol:

You have no idea what you've gotten yourself in to. If you're not using this camera to make high end digital content for money, take it back and get something more user friendly. Used GH5 should work nicely.
Offline

Denny Smith

  • Posts: 11116
  • Joined: Thu Aug 01, 2013 4:19 pm
  • Location: USA, Northern Calif.

Re: BMPCC 6K keeps stopping

PostWed Sep 11, 2019 11:08 pm

Or a Nikon Z6... :roll:
Most likely the OP is using the wrong SD card. Until he/she provides more info, we will not know what the issue is.
Denny Smith
SHA Productions
Offline

Yellowfin

  • Posts: 9
  • Joined: Sat Sep 07, 2019 7:26 am
  • Real Name: Justin Hewitt

Re: BMPCC 6K keeps stopping

PostWed Sep 11, 2019 11:48 pm

Folks

using a Sony 128GB SDXC II rated 300MB/s Read and 299MB/s Write; as that is the card I had handy. Its speed rating should be sufficient to handle more than 1 second of footage.
Also, even if it is dropping frames, it should not stop, if the stop on dropped frames option is off.

I have recently upgraded from the old BMPC 4K that had the slot for the SSD drive. Horrible battery, but writing to the internal SSD what never a problem on that unit.

I am planning to get the Wyse 1TB as the long term solution, but for now just trying to test out 6K 3.1 shooting.

Justin
Offline
User avatar

Jamie LeJeune

  • Posts: 1098
  • Joined: Tue Feb 26, 2013 4:33 am
  • Location: San Francisco

Re: BMPCC 6K keeps stopping

PostWed Sep 11, 2019 11:56 pm

Two things:

1) As others have already stated, it's quite likely that your recording media can't keep up. Either check the manual for the camera or the link below to the page where BMD lists which cards have been tested and confirmed to handle the various formats and frame rates. Make sure the media you are using is on that list for the format and frame rate you're trying to record.

Current manual can be downloaded from here: https://documents.blackmagicdesign.com/UserManuals/BlackmagicPocketCinemaCameraManual.pdf?_v=1567148400000

Current list of supported media is here: https://www.blackmagicdesign.com/support/faq/59026

2) On page 2 of the recording settings in the camera menu there is a toggle option called "Stop Rec if Card Drops Frames"

When toggled on, the camera will stop recording if your media drops frames. In virtually all cases you'd want to leave this option on, but if for some reason you don't care if frames are dropped and want the camera to always keep recording, you can toggle it off.
www.cinedocs.com
http://www.imdb.com/name/nm4601572/
Offline

John Brawley

  • Posts: 2115
  • Joined: Tue Aug 21, 2012 7:57 am
  • Location: London UK

Re: BMPCC 6K keeps stopping

PostThu Sep 12, 2019 12:07 am

Yellowfin wrote:Folks

using a Sony 128GB SDXC II rated 300MB/s Read and 299MB/s Write; as that is the card I had handy. Its speed



The manufacturers numbers are meaningless.

What matters is what numbers they get to when in use by this camera, that's much more high demand than almost any other camera.

What matters is if it's BMD supported media because they test it.

https://www.blackmagicdesign.com/support/faq/59025

If it's not on this list then it's not supported media.

JB
John Brawley
Cinematographer
London UK
Offline

Denny Smith

  • Posts: 11116
  • Joined: Thu Aug 01, 2013 4:19 pm
  • Location: USA, Northern Calif.

Re: BMPCC 6K keeps stopping

PostThu Sep 12, 2019 12:44 am

And the Sony 128GB SDXC II rated 300MB/s cards are not on the list.
You need to use the recording media listed by BMD as approved.
Denny Smith
SHA Productions
Offline
User avatar

rick.lang

  • Posts: 11450
  • Joined: Wed Aug 22, 2012 5:41 pm
  • Location: Victoria BC Canada

Re: BMPCC 6K keeps stopping

PostThu Sep 12, 2019 1:07 am

Last chance, be sure to format the card in the camera, nowhere else. Suggest exFAT format. If that fails, you know what to do!


Sent from my iPhone using Tapatalk
Rick Lang
Offline

Yellowfin

  • Posts: 9
  • Joined: Sat Sep 07, 2019 7:26 am
  • Real Name: Justin Hewitt

Re: BMPCC 6K keeps stopping

PostThu Sep 12, 2019 2:47 am

The card is a Sony SF-G128, It is not the TOUGH variant; but looking at the spec for the T variant, the difference is only the structural build of the card itself, not the electronics.

From the Blackmagic FAQ

The following SD cards are recommended for recording 6K 16:9 Blackmagic RAW 5:1 up to 30 fps.
* Angelbird AV PRO SD V90 64GB
* Sony Tough SF-G32T 32GB
* Sony Tough SF-G64T 64GB
* Sony Tough SF-G128T 128GB <-------------
* Toshiba Exceria Pro UHS-II 270MB/s SDXC 64GB
* Wise SD2-128U3 SDXC UHS-II 128GB

I have tried both format on PC and format inside the camera.
Offline
User avatar

rick.lang

  • Posts: 11450
  • Joined: Wed Aug 22, 2012 5:41 pm
  • Location: Victoria BC Canada

BMPCC 6K keeps stopping

PostThu Sep 12, 2019 3:39 am

It may not be electronics, but it might run a different version of the card’s data controller. Little card software changes can have big impacts in a cinema camera. And if you are correct that there may be something wrong with the camera, you may have to demonstrate that an approved card isn’t working either in your camera.
Rick Lang
Offline

Olivier Burri

  • Posts: 43
  • Joined: Sun Apr 24, 2016 7:15 am
  • Location: Geneva, Switzerland

Re: BMPCC 6K keeps stopping

PostThu Sep 12, 2019 5:19 am

Could also be a Battery issue.

I have seen such problem with faulty BMD compatible LP-E6 provided in the package.

I suggest to try with a fully charged original Canon batt and see if the problem persists.
Olivier G. Burri
Offline
User avatar

Peter J. DeCrescenzo

  • Posts: 2279
  • Joined: Wed Aug 22, 2012 6:53 am
  • Location: Portland, Oregon USA

Re: BMPCC 6K keeps stopping

PostThu Sep 12, 2019 5:52 am

Yellowfin wrote:The card is a Sony SF-G128, It is not the TOUGH variant; but looking at the spec for the T variant, the difference is only the structural build of the card itself, not the electronics.

From the Blackmagic FAQ

The following SD cards are recommended for recording 6K 16:9 Blackmagic RAW 5:1 up to 30 fps.
* Angelbird AV PRO SD V90 64GB
* Sony Tough SF-G32T 32GB
* Sony Tough SF-G64T 64GB
* Sony Tough SF-G128T 128GB <-------------
* Toshiba Exceria Pro UHS-II 270MB/s SDXC 64GB
* Wise SD2-128U3 SDXC UHS-II 128GB

I have tried both format on PC and format inside the camera.


The "SF-G128" is not labelled as a "V90" type card by Sony. V90 "video speed class" is required to handle the sustained write data rates of Pocket 4K & 6K cameras. "SF-G128T" cards are labelled as V90 by Sony.

Cheers.
-
http://www.peterdv.com
Offline

Yellowfin

  • Posts: 9
  • Joined: Sat Sep 07, 2019 7:26 am
  • Real Name: Justin Hewitt

Re: BMPCC 6K keeps stopping

PostThu Sep 12, 2019 7:44 am

Folks.

Thanks for your replies. It appears that particular Sony card is not good enough.
I have ordered a 256MB CF Card from the approved list and will order a Wise 1TB from B&H.

Justin
Offline
User avatar

rick.lang

  • Posts: 11450
  • Joined: Wed Aug 22, 2012 5:41 pm
  • Location: Victoria BC Canada

Re: BMPCC 6K keeps stopping

PostThu Sep 12, 2019 3:45 pm

I have the Wise Portable SSD 1TB and very happy with it; very light and comes with a mount.

Be careful with your language! You hopefully ordered a CFast 2 card and not a CF card as that’s incompatible (CF refers to Compact Flash) with BMD cameras.


Sent from my iPhone using Tapatalk
Rick Lang
Offline

Yellowfin

  • Posts: 9
  • Joined: Sat Sep 07, 2019 7:26 am
  • Real Name: Justin Hewitt

Re: BMPCC 6K keeps stopping

PostFri Sep 13, 2019 1:30 am

Thanks Rick. Yes, it is a Lexar 256GB CFAST 2.0 card 3400X speed as listed on the approved list
Offline

Krishna Pada

  • Posts: 223
  • Joined: Tue May 17, 2016 5:55 pm

Re: BMPCC 6K keeps stopping

PostFri Sep 13, 2019 6:53 am

rick.lang wrote:Last chance, be sure to format the card in the camera, nowhere else. Suggest exFAT format. If that fails, you know what to do!


Sent from my iPhone using Tapatalk


Rick, why do you suggest exFAT? I normally format my cards in Mac format, am I doing something wrong?
FILMWALLAH.
Resolve Studio. Mac Pro 5.1 12 core, 64 GB Ram, Titan X, 1 TB SSD System drive, 500 GB Resolve Cache, 12TB Internal Raid, High Sierra
Red S-W,UMP G2, BMD Pocket 6K, 5D Mark IV, A7s2
Zeiss CP.3 15, 25, 50, 85. Zeiss Contax 25, 35, 50, 85, 135.
Offline

Uli Plank

  • Posts: 4865
  • Joined: Fri Feb 08, 2013 2:48 am

Re: BMPCC 6K keeps stopping

PostFri Sep 13, 2019 9:43 am

Nothing wrong with that, but exFAT can be read by both platforms. If you use a Mac only, it doesn’t matter.
Resolve Studio and Fusion Studio
iMac 2017 Radeon Pro 580 8 GB VRAM and 32 GB RAM
Offline
User avatar

rick.lang

  • Posts: 11450
  • Joined: Wed Aug 22, 2012 5:41 pm
  • Location: Victoria BC Canada

Re: BMPCC 6K keeps stopping

PostSat Sep 14, 2019 1:07 am

Uli is correct and being able to easily handle exFAT on both platforms is helpful. But exFAT uses less resources and appears to be a little faster than HFS+ so if you have a performance issue, exFAT might help.


Sent from my iPhone using Tapatalk
Rick Lang
Offline

Uli Plank

  • Posts: 4865
  • Joined: Fri Feb 08, 2013 2:48 am

Re: BMPCC 6K keeps stopping

PostSat Sep 14, 2019 5:49 am

Yes, it’s a tiny bit faster. OTOH, exFAT is harder to salvage if something goes wrong.had a case with the disk in a WD Passport Pro.
Choose your poison…
Resolve Studio and Fusion Studio
iMac 2017 Radeon Pro 580 8 GB VRAM and 32 GB RAM
