Project setting for Anamorphic

PostSat May 03, 2025 8:31 pm

So sorry for the cross post (also in Resolve, no answers)..

I have a Sirui 35mm x1.6 Anamorphic lens (Saturn) if I shoot in 6k open gate what will be the correct project settings (resolution wise) in Resolve to retain 6k?

Is there an easy formula for working project settings out?
Offline
User avatar

dondidnod

  • Posts: 698
  • Joined: Sun Nov 25, 2018 7:52 am
  • Location: Castro Valley, CA
  • Real Name: Donald Keller

Re: Project setting for Anamorphic

PostWed May 07, 2025 6:08 pm

Sirui has a 2x solution for their Venus 1.6x anamorphic lenses:

1.25x anamorphic adapter

1.25x anamorphic adapter

1.25x anamorphic adapter
Offline
User avatar

rick.lang

  • Posts: 18618
  • Joined: Wed Aug 22, 2012 5:41 pm
  • Location: Victoria BC Canada

Re: Project setting for Anamorphic

PostWed May 07, 2025 7:36 pm

Wafubloke wrote:… I have a Sirui 35mm x1.6 Anamorphic lens (Saturn) if I shoot in 6k open gate what will be the correct project settings (resolution wise) in Resolve to retain 6k?


In the absence of a 1.6x pixel adjustment on the Media page Clip Attributes, you can just leave the setting at “square pixels” but on the Edit page / Inspector / Transform:

- unlink the X axis and Y axis
- set the Y axis at 0.625x.

That will retain the same 6K horizontal resolution and reduce the vertical resolution accordingly. You should also alter your Project Settings for the Timeline to the corresponding height.
Rick Lang
Offline

Wafubloke

  • Posts: 13
  • Joined: Sat Jun 17, 2023 6:45 pm
  • Real Name: Ash Daws

Re: Project setting for Anamorphic

PostThu May 08, 2025 12:24 pm

Thank you guys.
